Max: 220 m (722 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.
Wall Performance
Two wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'')
Gigabit RJ45 Ports
5
Ethernet Notes
1× WAN port, the rest are LAN ports
LED
Power
Internet
WAN
LAN
2.4 GHz Wi-Fi
5 GHz Wi-Fi
Physical Buttons
WPS Button
Reset Button
Power Input
DC Jack
Power Methods
DC
DC Input
12V 1A
Power Adapter
Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1A DC
Max Power Consumption (W)
9W
Reliability (Environment)
Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 95% non-condensing
Certifications
FCC, CE
Installation
Desktop
Wall-mount
Dimension
Device: 183.3×109×38 mm 7.22×4.29×1.5 inches
Each Antenna: 175 mm 6.89 inches
