EDFA WS50EYA2U 32×18dBm
- EDFA model: WS50EYA2U
- Output channels: 32
- Output power: 18 dBm per channel
- Band: C-band
- Application: Optical fiber amplification
Տեխնիկական բնութագիր
Specification
Value
Type
EDFA (Erbium‑Doped Fiber Amplifier)
Wavelength Range
1530–1565 nm (C‑band)
Output Power
32 × 18 dBm
Input Power Range
‑6 dBm to +10 dBm
Noise Figure
≤ 5 dB
Connectors
SC/APC, SC/UPC, LC/APC, LC/UPC
Power Supply
AC 220 V (90–265 V), AC110 V optional, 48 V DC optional
Power Consumption
≤ 100 W
Operating Temperature
‑5 °C … +42 °C
Storage Temperature
‑40 °C … +80 °C
Size
≈ 450 × 482 × 89 mm
Weight
≈ 12 kg
|
