Specification
Value
Model Version
L400 2.0
CPU - CPU Details
MTK
Memory/Storage - Flash/ROM
512Mbit (64MB) DDR 2
Memory/Storage - DDR/RAM
64Mbit (8MB) SPI Flash
Cellular - Cellular Standards
4G Cat. 4
Cellular - Cellular Antennas
4× Fixed
Cellular - SIM Options
1× Nano SIM Slot
Cellular - Available Versions
EU, CN
EU Version Cellular - Suitable Region
Europe, Middle East, Africa
EU Version Cellular - Max DL Speed
150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD)
EU Version Cellular - Max UL Speed
50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD)
EU Version Cellular - Advanced
DL 2×2 MIMO
EU Version Cellular - Cellular Bands
LTE-FDD: B1/3/5/7/8/20/28
LTE-TDD: B38/40/41
WCDMA: B1/5/8
CN Version Cellular - Suitable Region
China, India
CN Version Cellular - Max DL Speed
150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD)
CN Version Cellular - Max UL Speed
50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD)
CN Version Cellular - Advanced
DL 2×2 MIMO
CN Version Cellular - Cellular Bands
LTE-FDD: B1/3/5/8
LTE-TDD: B34/38/39/40/41
WCDMA: B1/5/8
GSM: B3/8
Wireless - 2.4 GHz Wi-Fi Speed
300 Mbps
Wireless - 2.4 GHz Wi-Fi Streams
2T2R (2×2 MIMO)
Wireless - Wi-Fi Antennas
4× Internal
Wireless - FEM or PA/LNA
2.4 GHz: 2× Internal
Wireless - Range Performance
Max: 100 m (328 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.
Wireless - Wall Performance
One wooden wall < 10 cm (4'')
One concrete wall < 10 cm (4'')
Interfaces - Physical Buttons
Interfaces
3x RJ45 10M/100M LAN Ethernet interfaces
1 x RJ45 10M/100M LAN/WAN Ethernet interfaces
Interfaces - LED
- System
- Cellular Signal Strength
Interfaces - Power Input
DC Jack
Power - Power Methods
DC
Power - DC Input
12V 1A
Power - Power Adapter
Input: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1A DC
Power - Max Power Consumption
8W
Power - Idle Power Consumption
3W
Reliability - EMC
ESD: Contact: 4kV; Air: 8kV
Reliability - Environment
Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
