FTTH outdoor drop cable 1 core Rope
-
1× SM G657A1 fiber
-
7× 0.4 mm Steel wires + 2× 0.5 mm FRP
-
2× 0.5 mm FRP rods + steel wire messenger
-
LSZH jacket, black, loose buffer
-
Bend radius ≥10× OD
-
Temp: -40°C ~ +70°C
-
Packaging: 1 km roll
Տեխնիկական բնութագիր
Specification
Value
Number of Cores
1
Fiber Type
Single Mode (SM) G657A1
Outer Jacket
LSZH (Low Smoke Zero Halogen)
Reinforcement Wires
7 x 0.40 mm Steel Wire (messenger) + 2 x 0.5 mm FRP
Core Structure
Loose Buffer
Outer Jacket Color
Black
Sheath Material
LSZH
Inner Reinforcement
2 x 0.5 mm FRP rods + Steel wire messenger
Operating Temperature
-40°C ~ +70°C
Storage Temperature
-40°C ~ +70°C
Minimum Bending Radius
≥10x cable diameter
Flexibility During Movement
Good
Packaging
1 km roll
Usage Environment
Outdoor
Compliance Standards
ITU-T G.657A1, IEC 60793, IEC 60794
|
