The PoE ports comply with IEEE 802.3at/af standards.
PoE Priority
Configurable. If no priority is configured, smaller-numbered ports have higher priority.
Shielded RJ45 Port
True
Extend Mode Ports
Configurable
VLAN Mode Ports
Configurable
LED
Power
PoE Status of Each PoE Port
Link/ACT of Each Ethernet Port
PoE Max Status
Power Interfaces
AC Inlet
Physical Buttons
Reset Button
Watchdog Note
The PoE Watchdog will attempt to reboot the plugged-in clients that have been inactive for 5 minutes. Do not turn it on for clients with online auto-upgrade feature.
Copper Speed and Distance
Cat. 3 or higher cable: 100 meters at 10 Mbps
Cat. 5 or higher cable: 100 meters at 100 Mbps
Cat. 5e or higher cable: 100 meters at Gigabit
Cat. 5e or higher cable: 250 meters at 10 Mbps
Copper Speed and Distance Note
250-meter transmission is available when the port speed is set at 10 Mbps in the software.
MAC Address Table
8192
Max Switching Capacity
56 Gbps
Max Forwarding Rate
41.664 Mpps
Jumbo Frame
15 KB
Packet Buffer
4 Mbit
Power Methods
AC
Power Input
100-240V~ 50/60Hz
Power Supply
300W
Max Power Excluding PoE
20W
Switching - 802.3 Protocols
802.3x Flow Control
802.3i 10BASE-T
802.3u 100BASE-TX
802.3ab 1000BASE-T
802.3z 1000BASE-X
802.3az Power Saving
802.3af PoE
802.3at PoE
802.1 Protocols
802.1d: STP
802.1w: RSTP
802.1p: LAN Layer 2 QoS/CoS
802.1q: VLAN Bridge Operation
802.1ab: LLDP/LLDP-MED
Port Management
Port On/Off
Port Negotiation Speed
Port Trunk (Static Aggregation)
Port Mirror
Data Rate Limit
Jumbo Frame Settings
Storm Control
Traffic Monitor
MAC Address Management
EEE (802.3az)
PoE Management
PoE Priority
PoE Watchdog On/Off
PoE Watchdog Period/Packet Threshhold
PoE Consumed Power
PoE Standard
Delayed PoE Delivery
Total PoE Power Limit
PoE Power Limit
Port Mirror Sessions
4
Port Trunk Groups
4
Max Port Num per Port Trunk Group
8
L2 Features
IGMP Snooping
Loop Prevention
DHCP Snooping
STP/RSTP
LLDP Config and Neighbors
MTU VLAN
Port-Based VLAN
802.1Q VLAN
Voice VLAN
DSCP QoS
802.1p QoS
Port-Based QoS
Fans
1
Fan Note
Smart Cooling: The fan speed adjusts in real time based on power consumption.
